Deskripsi
Capacity ( FAD ) : 14 m³/min
Inlet/Outlet : 2″
Length : 1156 mm
Width : 400 mm
Height : 1640 mm
Weight : 322 kg
STANDART CONDITION
Inlet air temperatur : ≤38°C
Ambient temperatur : ≤38°C
Working pressure : 0.7MPa
THE SCOPE OF WORK
Max inlet air temperatur : 50°C
Ambient temperatur : 45°C
Working pressure : 0.4-1.0MPa
Power : 220V / 50HZ / 1P
Pressure Dewpoint : -20°C – -40°C
Pressure Lose : ≤0.021MPa
